MOBILE PARKHOMES

Temporary comfortable accommodation solution anywhere
VIEW GALLERYVIEW PLANS

MOBILE PARKHOME

Our Parkhomes (also referred to as prefab buildings) are manufactured in a controlled factory environment.

The use of durable materials and quality fittings together with robust design ensures the quality for which our transportable buildings have become known.

The mobile parkhome units are available in various sizes and floor plans and can be tailored to the customer’s requirements. (Office plans |  Accommdation plans)

For a turnkey solution for you site, a variety of options are available including furniture, security and air conditioning.

mobile parkhomes

Our products offer a quick, easy and safe solution.

It is not a permanent structure on the land as the units can be moved if and when required. The green footprint is a major factor to consider as once the units have been relocated the land can easily be rehabilitated to its original state.

Using mobile parkhome accommodation instead of brick and mortar buildings for mines, construction sites or anywhere that needs temporary accommodation makes absolute sense.

CONSTRUCTION TIMELINES

Because mobile parkhome units are built indoors (in our factory) they can be completed in a matter of a few weeks as opposed to months. These constructions do not see the typical on-site delays that are predominantly caused by the weather. Or mobile units conform to specific rules, guidelines and building codes.

THE DETAILS

Delivery and settup on site.  Quality, easy maintainable finishes.  Quick turnaround.

THE FINISHING TOUCHES

We can supply custom furniture and finishes on request.  You may need a blackboard, custom shelves, lockers or more.  Landscaping, plumbing and electics – chat to us.  Our turnkey solutions make the process easier.

WE HAVE PLANS!

Get started with some of our downloadable office plans to see what you need.  Then request a quote with your specific requirements and let’s get started!

Chassis and Roof

Chassis
All steel 300mm or 200mm lipped channel with heavy duty cross members, complete with primer undercoat and covering enamel final coat. Self leveling screw in type jacks are included as part of the chassis construction. Note that there is no timber in the chassis construction.

Roof And Ceiling (Monopitch – 2.500mm to 2.300mm Fall)

The same panel system is used for the roof and ceiling, i.e. 0,6mm galvanised sheet for the roof and 0.58mm embossed chromadeck for the ceiling. Joints between the roof panels are sealed by the application of a membrane tape with sealant to the supplier specification. The insulation value of the roof and ceiling is the same as for the walls. Note that there is no timber in the roof construction.

Floors and Side Walls

Floors
18mm Thick exterior grade timber floor boards on steel cross bearers.

Sidewalls
60mm Thick 16FR (Fire retardant) Polystyrene core pressure bonded with 0.58mm ridgedised chromodeck on both sides.. Both exterior and interior skins are bonded to the polystyrene core by a pressure process resulting in an extremely strong panel. The external chromatic skin has a butt jointed profiled edge which gives a flush weatherproof joint.

Advantages of this system are:

  • The chromatic skin is bonded over the whole area, resulting in
    an extremely strong panel with a solid feel.
  • The 60mm thick polystyrene core has excellent insulation
    properties ( U-value = 0.6W/M² ºC),
  • is fire retardant (16FR) and does not give off poisonous gases in
    the case of a severe fire, as is the case of some Polyurethane /
    foam insulation materials.
  • No condensation problems – as can occur in timber cavity
    wall construction.[/tab]
Windows and Doors

Windows

Prefab Units are fitted standard with anodized aluminium top hung windows or as per client specifications.

Doors

Exterior :

Chromadeck clad 38mm panel, complete with 3 lever lock.

Interior:

Hollow core with wood grain skin complete with 2 lever lock.[/tab]

Electrical

Fitted as per unit requirements with 230 volt supply and Distribution Board. Wall switches and plug boxes are flush mounted in the wall panel with wiring concealed in the polystyrene core.

Plumbing

Plumbing

Units are plumbed using Copper piping for supply and PVC for waste and sewerage.

General

  • Kitchen and bedroom cupboards in oak melamine with postform tops to match or as per client specifications.
  • Floor cover to customer requirements, either 1.6mm / 2mm industrial vinyl or carpeting.
  • Air conditioners supplied and fitted as per customer requirements.
  • Burglar bars and security gates.
  • Curtains or blinds
  • Geysers – electric or gas as specified You will notice that our Units contain no timber framework in its construction, except for the weatherproof exterior grade floor boards.

Conventional Parkhome units are constructed almost entirely with timber, either in the roof or walls and may be prone to wood rot and moisture problems over time.

mobile parkhomes

NOTE: We strive to improve our products on a continuous basis and therefore reserve the right to change specifications without notice.

Polycore prefab

We get your mobile parkhome to any site!

We transport park and mobile homes, sites offices and shipping containers.

All units are transported by skilled drivers and crews, using specialized low-bed trucks to ensure safe delivery of your movable assets. Once on site we can erect and commission the buildings for use.
